Deploy Smarter, Not Harder: Cloudflare Tunnels for the Win

·685 words·4 mins· loading · loading · ·
Utkarsh Deoli
Author
Utkarsh Deoli
Just a developer for fun
Table of Contents

Cloudflare Tunnels: Securely Expose Local Applications to the Internet
#

Introduction
#

Over the past few months, I’ve been experimenting with setting up a small home lab, self-hosting various applications on my Raspberry Pi 4, and occasionally deploying my projects. Some of my favorite self-hosted applications include:

  • Nextcloud – A powerful alternative to cloud storage services.
  • Jellyfin – A feature-rich home media server.
  • VS Code Server – A remote-accessible coding environment.

However, accessing these applications remotely presents a few challenges. Traditionally, you would need:

  • A public IP address
  • A cloud or home server

Using a public IP can be risky, as it exposes your home network to potential security threats. While renting a VPS from a cloud provider is an option, hosting high-storage and high-RAM applications like Nextcloud and Jellyfin can quickly become expensive. So, what’s the alternative?

Enter Cloudflare Tunnels – a secure way to expose local applications to the internet without needing a public IP.

How Cloudflare Tunnels Work
#

Cloudflare Tunnels use a lightweight service called Cloudflared to create a secure, reverse tunnel between your local machine and Cloudflare’s global network. This allows you to expose applications on your local network to the public internet via a Cloudflare-managed domain, eliminating the need for port forwarding or a static IP.

Image Description

Key Benefits:
#

  • No need for a public IP.
  • Secure, encrypted connections.
  • Easy configuration and management.
  • Works with HTTP, SSH, RDP, and SMB traffic.

Here’s a simplified illustration of how Cloudflare Tunnels function:

[Local Application] → [Cloudflared] → [Cloudflare Edge] → [Public Internet]

Now, let’s set up our first tunnel!

![[Pasted image 20250319194624.png]]

Prerequisites
#

To follow along, you’ll need:

  1. A domain registered with Cloudflare.
  2. Cloudflare nameservers configured for your domain.
  3. A Cloudflare Zero Trust account (requires credit card verification).

Installing Cloudflared
#

Cloudflared is available on multiple platforms, including:

  • Linux (AMD64, ARM, ARM64, x86)
  • Docker
  • Windows
  • macOS

Installing on Linux
#

Run the following command (replace $ARCH with your system’s architecture):

wget -q https://github.com/cloudflare/cloudflared/releases/latest/download/cloudflared-linux-{$ARCH}.deb \
    && dpkg -i cloudflared-linux-{$ARCH}.deb

Authenticating Cloudflared
#

Once installed, authenticate your Cloudflare account:

cloudflared tunnel login

This will open a browser window for you to authorize the domain you want to use for tunnels. After logging in, Cloudflare saves your credentials at:

/home/$USER/.cloudflared/cert.pem

Creating a Test Application (NGINX)
#

To test our tunnel, let’s set up a simple NGINX server inside a Docker container.

Install Docker (if not already installed):
#

sudo apt update && sudo apt install docker.io

Run NGINX inside a Docker container:
#

docker run --name tunnel-nginx -p 5000:80 --detach nginx:latest

This command will:

  • Pull the latest NGINX image (if not available locally).
  • Name the container tunnel-nginx.
  • Map port 5000 on the host to port 80 inside the container.
  • Run the container in detached mode.

Verify the running container:

docker ps

Access NGINX at:

http://localhost:5000

Creating and Configuring the Cloudflare Tunnel
#

Step 1: Create the Tunnel
#

cloudflared tunnel create nginx-tunnel

This generates a credentials file and provides a Tunnel ID. Keep this file secure.

Step 2: Configure the Tunnel
#

Create a config file at /home/$USER/.cloudflared/nginx-tunnel.yml with the following content:

---
tunnel: <UUID>
credentials-file: /home/$USER/.cloudflared/<UUID>.json
ingress:
  - hostname: tunnel.<your-domain>
    service: http://localhost:5000
  - service: http_status:404

Replace <UUID> with your Tunnel ID and <your-domain> with your actual domain.

Step 3: Create a Public DNS Record
#

cloudflared tunnel route dns nginx-tunnel tunnel.<your-domain>

This will create a DNS record in Cloudflare that routes traffic through the tunnel.

Running the Tunnel
#

To start the tunnel, run:

cloudflared tunnel --config /home/$USER/.cloudflared/nginx-tunnel.yml run

Your NGINX server should now be accessible via https://tunnel**.** from the public internet!

Conclusion
#

With Cloudflare Tunnels, we securely exposed our local NGINX server to the internet without opening ports or requiring a public IP. This method ensures better security and flexibility, allowing us to host applications remotely with ease.

Beyond basic use cases, Cloudflare Tunnels can also:

  • Securely expose SSH, RDP, or SMB traffic.
  • Protect entire private networks with Cloudflare WARP.
  • Implement Cloudflare Access for granular security controls.

Start using Cloudflare Zero Trust today and explore the full potential of Cloudflare Tunnels!

Further Reading
#

  • Cloudflare Zero Trust Documentation
  • Cloudflare Tunnel Guide
